NXP Semiconductors TJx1410 10Base-T1S物理层收发器

The TJA1410 is designed for automotive and industrial applications, offering strong EMC performance, ISO 26262 ASIL B functional safety compliance, and full adherence to IEEE 802.3cg and OPEN Alliance (OA) TC14 specifications. The TJA1410 communicates over a simple 3‑pin OA interface, supports both local and remote wake‑up via TC10‑TC14, and enables advanced diagnostics such as topology discovery. Packaged in a small HVSON8 (3mm × 3 mm) format, it delivers high signal quality and low quiescent current, making the TJA1410 suitable for applications such as body control modules, lighting, and zonal ECUs.

NXP TJF1410将类似的能力扩展到工业环境，同时符合IEEE 802.3 cg和OPEN Alliance TC14规范，并支持TC10-TC14唤醒功能和拓扑结构发现等高级诊断功能。专为多点工业以太网设计，支持最多32个节点和最多100m电缆长度，同时维持强大的EMC性能和低功率。TJF1410采用紧凑的HVSON8封装，并兼容数据线供电 (PoDL)，非常适合PLC、电机驱动器、机器人、楼宇自动化和其他工厂网络设备。
